GV-RK1352 Card Reader


$100.00


Availability: In Stock
Ships within 1 to 12 Hours
List Price: $137.00
SKU: GV-RK1352 55-RK1352-0101
Product #: 85613
Manufacturer: Geovision

GeoVision Authorized Distributor Warranty:
Quantity

The GV-RK1352 is a card reader with keypad, designed to recognize PIN codes, identification cards or both. Featured with the Wiegand and RS-485 outputs, the unit can be connected to any standard access control panel. GV-RK1352 comes with a weather sealed and IP66 compliant housing for outdoor use.

  • Model No. GV-RK1352 card Reader
  • Ordering Part No. 520-RK1352-000
  • SKU 55-RK13520-0101
  • Card reader with keypad
  • Identification card and PIN code recognition
  • Weather-proof and IP66-compliant housing
  • RS-485 output: 9,600 bps, connect up to 8 GV-RK1352 units
  • 13.56 MHz for ISO14443A (MIFARE DESFire, MIFARE Plus and MIFARE Classic)



8-bit microprocessor
Frequency 13.56 MHz for ISO14443A ( MIFARE DESFire , MIFARE Plus and MIFARE Classic )
Wiegand Interface Wiegand 26 / 34 bits, distance 30 m (98.43 ft)
RS-485 9,600 bps, connect up to 8 GV-RK1352 units
Power DC 7.5V~12V
LED Red, Green and Blue LED
Beeper Buzzer
Color Black
Operating Temperature -35 °C ~ 65 °C (-31 °F ~ 149 °F)
Operating Humidity 10 ~ 90% RH (non-condensing)
Dimensions (W x H x D) 95 x 108 x 23 mm (3.74 x 4.25 x 0.91 in)
Weight 260 g / 0.57 lb
Ingress Protection IP66
Certification CE, FCC, RoHS
The number of GV-RK1352 supported by GV-AS Controllers
GV-AS Controller Model Interface
Wiegand RS-485
GV-AS100 1 1
GV-AS110 / GV-AS120 1 Not supported
GV-AS100 / GV-AS110 / GV-AS120 with GV-ASBOX 2 4
GV-AS100 / GV-AS110 / GV-AS120 with GV-ASNet Not Supported 2
GV-AS210 4 8
GV-AS400 8 8
GV-AS410 / GV-AS810 8 8
Options
GV-AS ID Card & GV-AS ID Tag GV-AS ID Cards and GV-AS ID Tags are ideal for business and residential environment, where access control is important for security reasons. 125 kHz and 13.56 MHz cards and tags are available.
*}
