ISO14443A MIFARE DESFire, MIFARE Plus and MIFARE
Classic, 13.56 MHz
DC 24V, 2.5A
DC 7.5V~12V, Max 250mA
0~50° C / 32~122° F
Dimensions (H x W x D)
130 x 54 x 43 mm (5.12 x 2.13 x 1.69 in)
130 g (0.29 lb)
1. For Card + Fingerprint Mode and Card Only Mode, it is required to
purchase GeoVision's cards and tags to work with.
2. Data synchronization with GV-AS Controller and GV-ASManager through
LAN is only supported
when the following controller firmware version and software version work
* GV-ASManager: V4.0 or later
* GV-AS100 / 110 / 120: V1.06 or later
* GV-AS400: V1.04 or later
* GV-AS210 / 810: V1.0 or later
* GV-AS410: V1.1 or later
3. All specifications are subject to change without prior notice.
GV-AS ID Card & GV-AS ID Tag
For Card + Fingerprint Mode,
the GV-AS ID F Card or GV-AS ID F Tag is required. For
Card Only Mode, both the GV-AS ID F Card / Tag and the
GV-AS ID Card / Tag are supported.
The GV-Hub V2 adds four RS-232/RS-485 serial ports through
the computer's USB port, allowing connection between the
fingerprint reader and the computer.
The GV-COM V2 can convert the standard RS-232 signal,
through USB connector, to RS-485 signal, allowing connection
between the fingerprint reader and the computer.
The GV-NET/IO Card is a RS-485 / RS-232 interface converter
that provides 4 inputs and 4 relay outputs. Using the GV-NET/IO
Card, you can connect the fingerprint reader to the computer.
PC Service Package
The package includes a USB cable for connecting the
fingerprint reader to a computer and a reader mount to hold the
reader for fingerprint enrollment.
