UNV Uniview 4 Ch NVR & (4) 4 Megapixel IR Vandal Dome Kit Professional Grade


Please login or register to see price
Availability: In Stock
Ships Same Day
SKU: UNV-4CH-NVR301-IPC324ER3-Kit
Product #: 87253
Manufacturer:
Shipping Lead Time: Ships Same Day





How to Program Your Uniview EZView App on Your Mobile Device









The most cost effective professional grade solutions from Uniview. The 4ch NVR and 4MP vandal dome camera kit can support high resolution live view and playback up to 4K(4000x3000). This NVR supports 1-8TB surveillance hard drives for increased storage and efficiency. All cameras are equipped with the latest Ultra 265 Video codec for reduced storage needs without losing any video quality. The NVR is integrated with a 4 port PoE switch to provide the connected cameras both power and data up to 928ft. (with extended transmission enabled)

This kit includes four 4MP vandal dome security cameras with 98ft of SmartIR night vision. It records high definition footage in 4MP (2K) resolution and is both outdoor rated and vandal proof.  All footage is recorded onto the included NVR and can be monitored remotely via mobile device or computer.





What’s Included:

· (1) 4 Ch, 4 Poe, 4K NVR
· (4) Uniview 4 Megapixel Vandal Dome IP Camera
· 1TB Surveillance Hard Drive
· 4x 100ft Cat5e Cables
· Free mobile apps and monitoring software
· Free lifetime technical support
· Free 3 Year Warranty

· HDMI & VGA Ports: Take full advantage of high definition video by using either HDMI or VGA cables.

· Remote Monitoring through our Free Apps: Download our free apps and view live footage and recordings right on your compatible smartphone or tablet.

· PC and Mac Compatible: Take advantage of the flexibility that our systems offer and review your recordings from any Mac or PC.

· Easy Backup Options: Save footage directly to a USB flash drive or to your PC in seconds flat. Options are also available to backup footage simultaneously to external SATA drives or FTP servers on your network, in the case that your main HDD should fail.



Highlighted Features






U.265 Compression


By combining U-Code and H.265, Ultra 265 can squeeze up to 95% bandwidth and storage space.

Unlike conventional video compression technologies which tries to reduce storage costs by sacrificing resolution and frame rate indiscriminately, U-Code chooses to use "IRP" (Intelligent Region Perception) to detect motion in each frame. Hence, scenes containing interesting information could be preserved while the other relatively static area such as lawns, white walls could be squeezed to save storage.




Cloud Upgrade


If your NVR is connected to a network with Internet access, you may utilize the Internet cloud update feature to check online to see if a new version is available and to perform the update.

Bring up the main menu by right-clicking with the mouse or left-clicking on the Home icon on the menu bar (if available). Using the mouse, left-click on Maintain and then Upgrade and then select the tab entitled Upgrade by Cloud. You will be shown the current version of firmware installed on the NVR and can click on the Check button at the bottom to see if a more recent version is available. If a new version is available, you need only to click on the Upgrade button at the bottom and the download and upgrade process will begin. After updating, the NVR will automatically reboot.




Smart Playback

In normal search, you had to take hours to search the whole playback bar to find the desired video clip.
In smart search, specify an interesting area and do smart search, it only takes seconds to find the desired video clip






Mobile App Push Notifications


Push Alerts & Automatic E-mails: Setup your Universal DVR/NVR to automatically send you an e-mail alert or a Push Notification, with video clip, every time there is a motion triggered or alarm event. This enables you to quickly take action when an incident has occurred




E-Map Function


The E-map feature provides a camera icon that represents the location of cameras on a map of a building or area, helping you to strategically place your cameras in the spots where surveillance is most needed. The detail this function provides is essential in saving time and the hassle of re positioning your cameras to achieve the desired viewing space.

**There are NO contracts or monthly fees with any WorldEyeCam purchase**


Model
NVR301-04-P4
Video/Audio Input
IP Video Input 4-ch
Network
Incoming Bandwidth 40Mbps
Outgoing Bandwidth 64Mbps
Remote Users 128
Protocols P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA Output HDMI:

3840x2160p /30hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz

VGA:

1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output 1-ch, RCA
Synchronous Playback 4-ch
Corridor Mode Screen 3/4
Decoding
Decoding format Ultra 265/H.265/H.264
Live view/ Playback 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability 1 x 4K@30fps, 2x 4MP@30FPS, 4 x 1080P@30, 4 x 720P@30
Hard Disk
SATA 1 SATA interface
Capacity Up to 8TB for each HDD
External Interface
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface Rear panel:2 x USB2.0
PoE
4 independent 100 Mbps PoEnetwork interfaces 2.4GHz
Max Power Max 30W for single port. Max 54W in total ( 13.5W for each )
Supported Standards IEEE 802.3at, IEEE 802.3af
General
Power Supply 48V DC

Power Consumption: ≤ 5 W( without HDD )
Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H) 260mm ×240mm × 44mm (10.2" × 9.4"× 1.7")
Weight ( without HDD )
≤ 1.12Kg(2.47lb)
Model IPC323ER3-DVPF28
Camera
Sensor 1/3", progressive scan , 4.0 megapixel, CMOS
Lens 2.8 mm@F2.0
DORI Distance Lens:
2.8mm: Detect (63m), Observe (25.2m), Recognize (12.6m), Identify (6.3m)
Angle of View (H) 104.4°
Angle of View (V) 67°
Angle of View (O) 135.7°
Adjustment angle Pan: 0°~360°; Tilt: 0°~75°; Rotate: 0°~360°
Shutter Auto/Manual, 1/1~1/100000 s
Min. Illumination Colour: 0.02 Lux (F2.0, AGC ON)

0 Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N
>55dB
IR Range Up to 30m (98 ft) IR range
Defog Digital Defog
WDR 120dB
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main Profile, High Profile
Frame Rate Main Stream: 4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps; 3MP (2048×1520): Max. 30 fps

Sub Stream: 2MP (1920×1080): Max. 30 fps;

Third Stream:D1 (720×576): Max. 30 fps
9:16 Corridor Mode Supported
HLC Supported
BLC Supported
OSD Up to 8 OSDs
Privacy Mask Up to 8 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
General Function Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication,
Storage
Edge Storage Micro SD, up to 128 GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP,
Compatible Integration ONVIF(Profile S, Profile G), API
Interface
Network 1 RJ45 10M/100M Base-TX Ethernet
Audio I/O Input: impedance 35 kΩ; amplitude 2 V [p-p]; Output: impedance 600 Ω; amplitude 2 V [p-p]
Alarm I/O 1/1
General
Power 12 V DC(+/-25%)
Power consumption: Max 5W
Dimensions (Ø x H) Φ108.5 x 81 mm (Ø4.28” x 3.2”)
Weight 0.45 kg (0.99 lb)
Working Environment -35°C ~ +60°C (-31°F ~ 140°F), Humidity:10%~90% RH(non-condensing)
Ingress Protection IP67
Vandal Resistant IK10

Average Customer Rating:


2 Most useful customer reviews
Fey Tina
Jun 9, 2014
This customer purchased the item at our site.
My previous security camera had no warranty and when it went faulty, I had no idea what to do. But this time I am very satisfied with this dome security camera kit which has so many features and has 3 years warranty, free mobile apps and monitoring software and above all technical support for free any time in life. I could not possibly find this huge offer with any other security kit. Now I can monitor all the outside area in detail whether night or day and can feel protected and safe
Loading...Was the above review useful to you? Yes (0) / No (0)
Jill Dando
May 11, 2014
This customer purchased the item at our site.
Once I installed 2MP security cameras in my office and was pretty satisfied by their performance but when I got this dome camera kit, I discovered how this updated version in 4 MP is offering me high definition footage with no defect. The best thing about it is that while driving or having holidays with my family I can monitor my office through my mobile phone. The footage can be saved for long time if necessary. NVR has video compressing technology, too – another great feature.
Loading...Was the above review useful to you? Yes (0) / No (0)

UNV Support


Uniview Support
Support Home

Uniview Quick Links


Uniview Remote Access Guides


Note! To Download Software Enter The Following Information:
Username: wec
Password: WEC1234$

Software Downloads


Networking


EZStation Client

Dealers and Installer Sign-up


Worldeyecam Dealers and CCTV Installers




Let's Get Started!

  • You must provide Worldeyecam, Inc with the Confidential Dealer / Reseller Application Form information.
  • Dealer LOGIN account will be created to display special discounted prices as an Worldeyecam Dealer/Distributor. You will be able to login and create quotes or simply order products at your discounted rate.
  • WorldEyeCAM, Inc. will add your business into our database of nationwide integrators and installers.
  • WorldEyeCAM, Inc will provide 1st Class Factory Trained technicians to provide fanatical technical support.
  • WorldEyeCAM, Inc. will advertise and promote your company on that we are partnered with installers that work in the area (cities and counties) that you service and cover.
  • When we get request for installation services in the area that you service, we will refer the customer to you for installation and sales.

Dealer Application
Click Here



Looking for a Quote from a local Installer? Click here



NVR Specs


The UNV (Uniview) 4K Recording Resolution 1 SATA Network Video Recorder



Product Features



  • 4 IP Channel Inputs
  • 4 Independent 100Mbps 802.3at PoE+ Interfaces
  • 1 HDMI and 1 VGA Video Outputs
  • Up to 8MP (4K) Recording Capability
  • Support H.265/H.264 video formats
  • 1 10/100Mbps Network Interface
  • 1 SATA Interfaces for Internal Storage
  • ONVIF Complianth



Remote Monitoring

Central Monitoring System: Have more than one location? Well accessing each of them on a different IP address is a thing of the past with our standard CMS software that allows you to painlessly link an almost unlimited number of recorders and cameras all to the same IP address.

Playback and Recording

Multiple Playback and Recording Options: The multiple recording options allow you to set your Universal DVR/NVR to record on a set schedule, continuously around-the-clock, or to further conserve hard drive space: only when motion is detected. You can also select the number of cameras to view on one screen or hide certain ones from other users, using the multiple playback features.

H.264 Compression

H.264 Real-time Recording and Playback: Its H.264 compression greatly reduces the size of your digital video files without compromising the image quality (compared to other compression standards, such as M-JPEG and MPEG-4). H.264 is a stable, proven compression technology, which offers unbeatable recording picture quality while at the same time saving you valuable hard drive storage space.

H.265 Compression

H.265 Real-time Recording and Playback: H.265 is a step above H.264. In the world of technology, we all strive to move forward and advance--so here is our next offer in the world of saving space and slow internet speeds. H.265 can transfer HD video data (~720p) at half of the bandwidth then that of H.264 so that you can enjoy 2K and 4K videos even if you have slow internet(1~2Mbs). You get the same data quality as H.264 and the others, but compared you save 70~80% in bandwidth sources.

Push Alerts

Push Alerts & Automatic E-mails: Setup your Universal DVR/NVR to automatically send you an e-mail alert or a Push Notification, with video clip, every time there is a motion triggered event. This enables you to quickly take action when an incident has occurred.

E-map Function

E-map Function Support: The E-map feature provides a camera icon that represents the location of cameras on a map of a building or area, helping you to strategically place your cameras in the spots where surveillance is most needed. The detail this function provides is essential in saving time and the hassle of re positioning your cameras to achieve the desired viewing space.

PTZ Control

3D Intelligent Positioning: This features let you digitally control your PTZ cameras (move up, move down, move left, move right, zoom in and zoom out) from your monitor and mobile applications.

Custom System Design

Worldeyecam offers free consultations and system designs, so if the bundled kits don't have what you need, please do not hesitate to call us (1-888-211-2288) or send in a sales request or e-mail. We are open Monday through Friday at 8AM to 5PM Pacific time.


**There are NO contracts or monthly fees with any WorldEyeCam purchase**


SPECIFICATIONS
Model NVR301-04L-4P
IP Camera Inputs 4 Channels
Two-way Talk 1 Channel, RCA Mic / Speaker Interfaces
Display Interface 1 HDMI, 1 VGA
Display Resolution HDMI: 4K (3840 x 2160); 1920 x 1080; 1600 x 1200; 1280 x 720; 1280 x 1024; 1024 x 768
VGA: 1920 x 1080; 1600 x 1200; 1280 x 720; 1024 x 768
Display Split 1 / 4
Recording Resolution 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF
Incoming Bit Rate 40Mbps
Outgoing Bandwidth 64Mbps
Alarm Inputs n/a
Relay Outputs n/al
Synchronized Playback 1 x 4K@30fps / 3 x 4MP@20fps / 4 x 1080p@30fps
Backup Media External USB or Network Download
Network interface 1 10/100/1000M RJ-45 Ethernet Interface
Remote Connections 128 Connections Maximum
HDD Interfaces 1 SATA interfaces
USB Interfaces 2 USB 2.0 Ports
Power Requirement DC48V
Power Consumption < 8W
PoE Ports 4
PoE Power Max 30W for each port, 54W Total Power Budget
Operating Environment 14° - 131° Fahrenheit
Dimensions 8.1” x 8.1” x 1.7”
Weight (without HDD) ~1.3lbs

Camera Specs




The UNV (Uniview) 4MP WDR Vandal-resistant Network IR Fixed Dome Camera. This is a 4 megapixel resolution IP Dome camera. It has an 2.8mm, 3.6mm, or lens. Infrared night vision allows the security camera to see up to 98 feet in total darkness. The surveillance camera also comes equipped with True 120dB Wide Dynamic Range and is ONVIF compliant. It is small and discreet but durable, with an IP66 rating.




Featured Video


Product Features

Optics

  • Day/night functionality
  • Smart IR , up to 30 m (98 ft) IR distance
  • Up to 120 dB WDR (Wide Dynamic Range)
  • 3D DNR (Digital Noise Reduction)
  • Compression

  • H.265, H.264, MJPEG
  • Embedded smart algorithm
  • Triple streams
  • ROI (Region of Interest)
  • Network

  • ONVIF Conformance
  • Structure

  • Wide temperature range: -35°C to 60°C (-31°F to 140°F)
  • Wide voltage range of ±25%
  • 4 KV surge protection designed for network interface
  • IP66

  • Infrared

    Smart IR Technology: This item comes with infrared technology, meaning not only can you see a longer distance in the dark but to bump up the ante, it also has "Smart IR" which will adjust based off of the situation to give you an optimal image.

    H.264 Compression

    H.264 Real-time Recording and Playback: Its H.264 compression greatly reduces the size of your digital video files without compromising the image quality (compared to other compression standards, such as M-JPEG and MPEG-4). H.264 is a stable, proven compression technology, which offers unbeatable recording picture quality while at the same time saving you valuable hard drive storage space.

    H.265 Compression

    H.265 Real-time Recording and Playback: H.265 is a step above H.264. In the world of technology, we all strive to move forward and advance--so here is our next offer in the world of saving space and slow internet speeds. H.265 can transfer HD video data (~720p) at half of the bandwidth then that of H.264 so that you can enjoy 2K and 4K videos even if you have slow internet(1~2Mbs). You get the same data quality as H.264 and the others, but compared you save 70~80% in bandwidth sources.

    Custom System Design

    Worldeyecam offers free consultations and system designs, so if the bundled kits don't have what you need, please do not hesitate to call us (1-888-211-2288) or send in a sales request or e-mail. We are open Monday through Friday at 8AM to 5PM Pacific time.


    SPECIFICATIONS
    Model IPC324ER3-DVPF36
    Camera:
    Sensor 1/3” progressive scan, 4 megapixel, CMOS
    Lens 2.8mm@F2(Angle of view(H): 93.5°)
    3.6mm@F2(Angle of view(H): 72.0°)
    6mm@F2(Angle of view(H): 42.0°)
    AWB(Auto white balance) Auto/manual
    Shutter Auto/Manual, shutter time: 1/6 s ~1/8000 s
    Minimum Illumination Colour: 0.02 Lux (F2.0, AGC ON)
    0 Lux with IR on
    Noise Reduction 2D/3D
    Day / Night IR-cut filter with auto switch (ICR)
    Gain Control Auto/manual
    IR Up to 30m (98 ft) IR range
    WDR 120dB
    Video
    Max. Resolution 2592 × 1520
    Compression H.265/H.264/MJPEG
    Frame Rate 4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps
    Video Streaming Triple
    9:16 Corridor Mode Supported
    OSD Up to 8 OSDs
    Privacy Mask Up to 4 areas
    Motion Detection Up to 2 areas
    Smart
    Behavior Detection Intrusion, crossing line, motion detection
    Intelligent Identification Face detection
    Statistical Analysis People counting
    Exception Detection Audio detection
    Storage
    Edge Storage Micro SD, up to 128GB
    Network
    Protocols L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x
    Compatible Integration ONVIF, API
    Interface
    Network 10M/100M Base-TX Ethernet
    General
    Power 12 V DC, or PoE (IEEE802.3 af)
    Dimensions (Ø x H)
    Power consumption: Max 5.5 W
    Φ126 x 94mm (Φ5.0” x 3.7”)
    Weight 0.33kg (0.73lb)
    Working Environment -35℃~60℃ (-31℉ ~ 140℉), Humidity ≤ 95% RH (non-condensing)
    Vandal Resistant IK10
    Ingress Protection IP66
