ORDERING NUMBER:125-LPR00LR2812-001
SKU:86LPR00LR2812DLND001
UPC:4711280521647
Overview:
The GV-LPR2812-DL is a 2-megapixel IP bullet camera developed by GeoVision, engineered specifically for automatic license plate recognition (ALPR). It is equipped with a built-in deep learning processor, enabling onboard recognition of license plates from vehicles moving at speeds up to 100 km/h (approximately 62 mph). This makes it ideal for access control, traffic monitoring, gated entries, and parking lot management.
Key Features:
Resolution and Sensor
The camera features a 2-megapixel 1/2.8” progressive scan CMOS sensor, capable of delivering clear, high-quality images suitable for license plate capture in both day and night environments.Lens and Zoom
Comes with a motorized varifocal lens (5.1 mm to 51 mm) providing 10x optical zoom. This allows users to adjust the focus and zoom remotely for different installation distances.Deep Learning-Based LPR
Integrates a deep learning algorithm for real-time license plate recognition directly on the camera, eliminating the need for external servers or software.Dual Lane Monitoring
Supports simultaneous recognition of license plates in two traffic lanes, improving efficiency in high-traffic zones.Illumination and Night Vision
Equipped with smart IR LEDs, the camera provides infrared illumination up to 22 meters. This ensures consistent license plate capture even in total darkness.Low-Light Performance
Features a minimum illumination of 0.04 lux (color) and 0 lux with IR on, offering reliable functionality in low-light conditions.Wide Dynamic Range (WDR Pro)
WDR Pro enhances visibility in challenging lighting situations such as scenes with both bright and dark areas, making license plates readable under headlight glare or backlighting.Ingress and Impact Protection
Rated IP67 for water and dust resistance and IK10 for vandal resistance, making it suitable for harsh outdoor environments.Power Options
Supports 12V DC and PoE (Power over Ethernet, IEEE 802.3af), providing flexibility in installation and wiring.Storage Capability
Built-in microSD card slot supporting SD/SDHC/SDXC (UHS-I, Class 10) cards for edge storage and backup.Audio and Alarm I/O
Supports two-way audio communication and includes one digital input and one digital output for integration with external alarm systems or gate controls.
Typical Applications:
Residential Complexes and Gated Communities
To control vehicle entry and exit automatically based on license plate data.Commercial Parking Facilities
For time-based access control, entry logs, and automated billing systems.Government and Military Facilities
For enhanced perimeter control and secure access enforcement.Industrial Sites and Logistics Hubs
For monitoring vehicle flow, time tracking, and compliance verification.
Summary:
The GV-LPR2812-DL is a specialized, AI-powered license plate recognition camera that combines high image quality, smart IR illumination, and built-in processing capabilities. Its weatherproof and vandal-resistant housing makes it a durable and reliable solution for outdoor applications where accurate, automated vehicle identification is required.
