Customizable Hybrid GeoVision NVR/DVR: Supports 1 up to 32 IP Megapixel Cameras NVR Network Video Recorder

Name: Customizable Hybrid GeoVision NVR/DVR: Supports 1 up to 32 IP Megapixel Cameras NVR Network Video Recorder
Brand: Geovision

Ask A Question Printable Version

$1,451.00

Availability: Ships within 1 to 12 Hours

List Price: ~~$12,104.00~~

SKU: NVR-RACK-G-WEC

Product #: 36929

Manufacturer:

Keywords: High Definition 1.3MP to 5 Megapixel: Supports 1 to 32 IP Megapixel Cameras NVR Network Video Recorder

Description: High Definition 1.3MP to 5 Megapixel: Supports 1 to 32 IP Megapixel Cameras NVR Network Video Recorder

Shipping Lead Time: Ships within 1 to 12 Hours

Recorder Type: DVR

IP NVR CPU CORE:

POS DATA Capture:

NVR Specs:

Hybrid Analog Input Options:

Windows Software:

GV-Control Center:

System OS Hard Drive:

First Hard Drive:

Second Hard Drive:

Third Hard Drive:

Fourth Hard Drive:

Fifth Hard Drive (Rackmount Required):

Sixth Hard Drive (Rackmount Required):

Seventh Hard Drive (Rackmount Required):

Eighth Hard Drive (Rackmount Required):

RAID Controller Option(s):

Upgrade Power Supply Unit:

Memory RAM:

Flat Panel LCD Monitor:

2nd Gigabit Network Port:

System Case:

Additional Video Card:

Remote Login Support:

Warranty:

Quantity

Description

The iMaxCamPro Dome Camera has audio... What will yours hear?

The Customizable Hybrid GeoVision NVR/DVR supports up to 32 IP Megapixel Surveillance Cameras. The GV-NVR (Network Video Recorder) records video and audio data over TCP/IP networks. This recorder is customizable to fit your specific needs; select the desired core processor, HDD space, Analog outputs and much more. One of the great features of using a Geovision by Worldeyecam surveillance system is that, provided the PC's minimum requirements have been met, you can add IP cameras to your existing analog Geovision system. Add this versatile GeoVision NVR/DVR to your surveillance system today.

NVR/DVR Specs

System		Customizable Hybrid GeoVision NVR/DVR
CPU		Intel Core i3 Processor Intel Core i5 Processor (Optional) Intel Core i7 Processor (Optional)
RAM		RAM 4 GB Dual Channels (*Optional: Up-gradable up to 32 GB of RAM)
No. of HDD Slots (SATA)		4 (3.5” HDD; SATA3 interface) *Up to 6TB per Hard Drive
Internal Storage Included		500 GB (Operating System Drive)
Operating System		64‐bit Windows 7 OS
Direct X		11
Connector	Ethernet	RJ‐45, 10 / 100 / 1000 Mbps x 2
	Video Output	VGA, DVI‐D and HDMI
	USB 2.0	Front: 2 ports, Rear: 4 ports
	USB 3.0	Rear: 2 ports
Environment
Operating Temp.		0 ~ 45 °C / 32 ~ 113 °F
Humidity		0 ~ 80% RH (non‐condensing)
Physical
Color		H.264, MJPEG
Dimensions (W x H x D)		19.7" x 19.1" x 7.0"
Net Weight		45 lbs

GeoVision Software

Video and Audio
Video Standard	NTSC, PAL
Video Input	16 channels (analog) and up to 32 channels (IP) (Max. 32 channels)
Video Input Level	1.0 Vp‐p (± 10%) composite, 75 Ω
Audio Input	16 channels (analog) and up to 32 channels (IP) (Max. 32 channels)
Audio Input Level	0.5 ~ 1 Vp‐p composite
Video Compression Format	HW: H.264 SW: Geo MPEG4, Geo H.264, MJPEG
Display Rate (Max)	NTSC: 480 FPS PAL: 400 FPS
Recording Rate (Max)	NTSC: HW: 480 (D1) PAL: HW: 400 (D1)
Video Resolution	NTSC: HW: 704 x 480, SW: 352 x 240 PAL: HW: 704 x 576, SW: 352 x 288
Live View and Playback
Image Control	Contrast / Brightness / Saturation / Hue
Recording Mode	Round the Clock / Motion Detection / Sensor Detection / Pre & Post Recording / Schedule Recording
Pre Recording	1~ 45 min.
Instant Playback	10 sec. / 30 sec. / 1 min. / 5 min.
Watermark	Supported
Searching and Playback
Search Method	Date / Time / Camera / Event Type
Backup Type	DVD+R (DL) / DVD‐R (DL) / DVD+R / DVD+RW / DVD‐R / DVD‐RW / CD‐R / CD‐RW
Remote Monitoring
Monitoring Environment	Web browser (IE, Chrome, Firefox and Safari) Mobile device (Android Smartphone and tablet; iPad, iPhone and iPod Touch)
Live View Max.	32–channel multi views (Up to 200 channels connection to GV-Tower System V2)
Recovery	Windows Recovery from internal OS HDD
System Monitoring and Recovery
Power Restoration	Automatic restart after power outage
Monitoring	Two independent Watchdogs (Hardware Watchdog + Software Watchdog)
Network Type	LAN, WAN, Internet
Software Language
Type	Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian/ Indonesian / Italian / Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish
Software License
Free License	32 channels from GV‐IP devices
Maximum License	32 channels from third‐party IP devices
Increment for Each License	1 to 32 third‐party IP cameras in increments of 2
Optional Combinations	N/A
Dongle Type	External

GV-VMS Software
Click/Tap on image for a more detailed view.

Additional GV-VMS Features:

Monitoring: The GV-VMS Software allows you to monitor up to 32 channels of video streams, E-map, PTZ control, among other functions.

Intelligent Recording, Smart Search and Easy Playback: Continuous recording (round-the-clock) and recording triggered by motion detection, alarm and schedule.

Video Merging and Export: Exporting video recording within a specified time range, exporting videos in EXE format, playable with any third-party players.

Video Analytics: The GV-VMS offer you different kind of video analytics such as: object counting, people counting, intrusion alarm, face detection, privacy mask, among other functions.

Integration with Centralized Management Software: The GV-VMS software is able to connect with the GV-Center V2, GV-Sign Monitor, GV-Dispatch and GV-Control Center.

Remote Monitoring Software: The GV-VMS software also allows you to monitor your security cameras remotely using the WebCam web interface, GV-Mobile Server app, GV-Edge Recording Server (Windows /Mac)*, GV-Eye app for Android Smartphones and iPhone / iPod / iPad.
