16-Ports 100Mbps Unmanaged PoE Switch


$315.00


Availability: In Stock
List Price: $400.00
SKU: POE-SW1602
Product #: 87019
Manufacturer:

Quantity

  • IEEE 802.3at and IEEE802.3af PoE compliant
  • Provides up to 30 watts per PoE port
  • Supports PoE power up to 230W for all ports
  • 4kV surge Protection for PoE ports
  • Plug and Play Installation
  • 7.2 Gbps switching fabric
  • 2.75 Mbits RAM Data Buffer
  • 4K MAC address Entries
  • Sturdy Metal Enclosure
  • Limited Lifetime Warranty

There have been no reviews

Specifications


Ports


  • Network Ports18

Standard

  • Network ProtocolIEEE802.3, 802.3u, 802.3x, 802.3af, 802.3at

Performance

  • Switching Capacity7.2Gbps
  • Uplink Port1000M Combo Port,2
  • Max. Forwarding Rate5.36Mpps
  • High Priority PortsPorts 1-8
  • Forwarding ModeStore-and-forward
  • MAC Address Table4k
  • Flow ControlIEEE802.3x full duplex

Power Over Ethernet

  • PoE Port16
  • PoE Standard802.3af, 802.3at
  • PoE Power Budget230W
  • Working ModeSupports 8 pins powering

General

  • Power Supply100-240V AC, 50/60Hz
  • Power Consumption≤250W
  • Working Temperature32°F ~ 104°F(0°- 40°)
  • Working Humidity10 % ~ 90 %
  • Surge Protection4KV
  • Dimensions440 × 285 × 43mm(17.33" × 11.22"× 1.69")
  • Weight≤ 3.72kg(8.14lb)
