SD435-PG-0 SPECTRA IV PND GRY 35X D/N SMK
SKU: SD435-PG-0
The Pelco SD435-PG-0 Spectra IV SE Dome System is a
video surveillance color camera offering 22x optical and 12x digital
zoom. With just three main components - the back box, a dome drive, and a
lower dome - the unit offers hassle-free installation and maintenance.
The back box memory stores camera and dome settings. The lower dome
bubble is designed to properly coordinate with the lens for clear images
even at long focal lengths.
With 256 presets, the Spectra IV Camera offers a +/- 0.1° preset accuracy. An internal scheduling clock enables systematic scheduling of the presets and patterns.
The Spectra IV Dome System has an on-screen compass and tilt display feature that helps in determining positions. The window blanking feature allows up to 8 four-sided privacy areas to be set by the user. Eight programmable zones can be labeled with a maximum of 20 characters each or can be set to output blank video. The zone automatically adjusts in size as the lens zooms telephoto and wide. The 7 alarm inputs can be programmed to initiate a pattern or preset and, thereafter, return back to the pre-alarm state when the alarm is acknowledged.
Capable of smooth pans across a range of speeds from 0.1°/second to 150°/second, the Spectra IV Dome allows programmable zoom speeds. The pan/tilt speeds can be configured to decrease proportionately to the depth of zoom. The scan speed can be adjusted between 1 and 40°/second. Almost all directions around the camera can be covered with continuous rotation across 360°. The 180° 'auto flip' rotation allows the dome to reposition itself for continuous monitoring of any subject passing even directly beneath.
The Spectra IV Dome incorporates an EXview HAD (Hole-Accumulation Diode) imager that enhances light sensitivity in dark areas. This HAD CCD (Charge-Coupled Device) senses light near the infrared frequency region, invisible to the naked eye. The automatic 'white balance' feature further improves the image quality; taking a standard white color reference, the RGB (red, green, and blue) colors are adjusted to get good quality images in varied light conditions. Automatic iris control adjusts the amount of light passing through the lens. The automatic white balance and iris control settings can be manually overridden by the user for getting the best image.
Password-protection ensures that settings cannot be tampered by unauthorized persons. The Spectra IV unit also offers a camera title overlay feature with 20 user-definable characters. An RJ-45 data port allows setting up and updating the dome drive's software.
The Spectra IV Camera also has a 'freeze frame between presets' facility that ensures a seamless frame transition between presets. The intuitive on-screen programming display is available in 10 languages (English, Spanish, Portuguese, Italian, French, German, Russian, Polish, Turkish, and Czech).
Surge protection ensures that the Spectra IV Camera is not damaged during voltage fluctuations. The integrated passive Unshielded Twisted Pair (UTP) circuitry makes for simple and efficient video transmission.
The Spectra IV is certified by the Federal Communications Commission (FCC) and CE as a Class B device.
With 256 presets, the Spectra IV Camera offers a +/- 0.1° preset accuracy. An internal scheduling clock enables systematic scheduling of the presets and patterns.
The Spectra IV Dome System has an on-screen compass and tilt display feature that helps in determining positions. The window blanking feature allows up to 8 four-sided privacy areas to be set by the user. Eight programmable zones can be labeled with a maximum of 20 characters each or can be set to output blank video. The zone automatically adjusts in size as the lens zooms telephoto and wide. The 7 alarm inputs can be programmed to initiate a pattern or preset and, thereafter, return back to the pre-alarm state when the alarm is acknowledged.
Capable of smooth pans across a range of speeds from 0.1°/second to 150°/second, the Spectra IV Dome allows programmable zoom speeds. The pan/tilt speeds can be configured to decrease proportionately to the depth of zoom. The scan speed can be adjusted between 1 and 40°/second. Almost all directions around the camera can be covered with continuous rotation across 360°. The 180° 'auto flip' rotation allows the dome to reposition itself for continuous monitoring of any subject passing even directly beneath.
The Spectra IV Dome incorporates an EXview HAD (Hole-Accumulation Diode) imager that enhances light sensitivity in dark areas. This HAD CCD (Charge-Coupled Device) senses light near the infrared frequency region, invisible to the naked eye. The automatic 'white balance' feature further improves the image quality; taking a standard white color reference, the RGB (red, green, and blue) colors are adjusted to get good quality images in varied light conditions. Automatic iris control adjusts the amount of light passing through the lens. The automatic white balance and iris control settings can be manually overridden by the user for getting the best image.
Password-protection ensures that settings cannot be tampered by unauthorized persons. The Spectra IV unit also offers a camera title overlay feature with 20 user-definable characters. An RJ-45 data port allows setting up and updating the dome drive's software.
The Spectra IV Camera also has a 'freeze frame between presets' facility that ensures a seamless frame transition between presets. The intuitive on-screen programming display is available in 10 languages (English, Spanish, Portuguese, Italian, French, German, Russian, Polish, Turkish, and Czech).
Surge protection ensures that the Spectra IV Camera is not damaged during voltage fluctuations. The integrated passive Unshielded Twisted Pair (UTP) circuitry makes for simple and efficient video transmission.
The Spectra IV is certified by the Federal Communications Commission (FCC) and CE as a Class B device.
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
SD435-PG-0 SPECTRA IV PND GRY 35X D/N SMK
Specifications :
The Pelco SD435-PG-0 Spectra IV SE Dome System is a
video surveillance color camera offering 22x optical and 12x digital
zoom. With just three main components - the back box, a dome drive, and a
lower dome - the unit offers hassle-free installation and maintenance.
The back box memory stores camera and dome settings. The lower dome
bubble is designed to properly coordinate with the lens for clear images
even at long focal lengths.
With 256 presets, the Spectra IV
Camera offers a +/- 0.1° preset accuracy. An internal scheduling clock
enables systematic scheduling of the presets and patterns.
The
Spectra IV Dome System has an on-screen compass and tilt display feature
that helps in determining positions. The window blanking feature allows
up to 8 four-sided privacy areas to be set by the user. Eight
programmable zones can be labeled with a maximum of 20 characters each
or can be set to output blank video. The zone automatically adjusts in
size as the lens zooms telephoto and wide. The 7 alarm inputs can be
programmed to initiate a pattern or preset and, thereafter, return back
to the pre-alarm state when the alarm is acknowledged.
Capable of
smooth pans across a range of speeds from 0.1°/second to 150°/second,
the Spectra IV Dome allows programmable zoom speeds. The pan/tilt speeds
can be configured to decrease proportionately to the depth of zoom. The
scan speed can be adjusted between 1 and 40°/second. Almost all
directions around the camera can be covered with continuous rotation
across 360°. The 180° 'auto flip' rotation allows the dome to reposition
itself for continuous monitoring of any subject passing even directly
beneath.
The Spectra IV Dome incorporates an EXview HAD
(Hole-Accumulation Diode) imager that enhances light sensitivity in dark
areas. This HAD CCD (Charge-Coupled Device) senses light near the
infrared frequency region, invisible to the naked eye. The automatic
'white balance' feature further improves the image quality; taking a
standard white color reference, the RGB (red, green, and blue) colors
are adjusted to get good quality images in varied light conditions.
Automatic iris control adjusts the amount of light passing through the
lens. The automatic white balance and iris control settings can be
manually overridden by the user for getting the best image.
Password-protection
ensures that settings cannot be tampered by unauthorized persons. The
Spectra IV unit also offers a camera title overlay feature with 20
user-definable characters. An RJ-45 data port allows setting up and
updating the dome drive's software.
The Spectra IV Camera also
has a 'freeze frame between presets' facility that ensures a seamless
frame transition between presets. The intuitive on-screen programming
display is available in 10 languages (English, Spanish, Portuguese,
Italian, French, German, Russian, Polish, Turkish, and Czech).
Surge
protection ensures that the Spectra IV Camera is not damaged during
voltage fluctuations. The integrated passive Unshielded Twisted Pair
(UTP) circuitry makes for simple and efficient video transmission.
The Spectra IV is certified by the Federal Communications Commission (FCC) and CE as a Class B device.
- Pendant Mount
- Lt. Gray Body
- Smoked Bubble
- 3 autofocus, high resolution integrated camera/optics packages
- 35x optical/12x digital zoom
- 256 presets with ±0.1° accuracy
- Internal scheduling clock schedules presets and patterns
- On-screen compass and tilt display
- Window blanking with 8 four-sided user-defined privacy areas
- 7 alarm inputs
- Alarm action: Alarms individually programmed for 3 priority levels, to initiate a stored pattern, or to go to an associated preset when received
- After-alarm action: The dome returns to a previously programmed state after alarm acknowledgement or to its previous position before alarm
- Pan speed adjustable between 0.1°/second to 150°/second
- Programmable zoom speeds
- Scan speed adjustable between 1 and 40°/second
- Continuous rotation across 360°
- 180° 'auto flip' rotation
- Programmable zoom speeds
- Automatic white balance with manual override
- Automatic iris control for controlling light passing through the lens
- Password protection
- Camera title overlay, 20 user-definable characters
- RJ-45 data port for software update and setup
- Freeze frame during presets
- 400°/sec pan preset speed and 200°/sec tilt preset speed
- Intuitive on-screen programming display in 10 languages (English, Spanish, Portuguese, Italian, French, German, Russian, Polish, Turkish, and Czech)
- Built-in surge and limited lightning protection
- Integrated passive Unshielded Twisted Pair (UTP) circuit
- Autosensing protocol (Coaxitron, RS-422 P and D); accepts competitive control protocol with optional translator card
- Digital position and zoom control and feedback through D protocol
- Ability to add IP network capability by purchasing optional TXB-IP module
Specifications :
| Signal System | NTSC |
| Image Sensor | 1/4" Color EXview HAD CCD |
| Number of Pixels | 768 x 494 |
| Resolution | 540 TVL |
| Lens |
Focal Length: 3.4-119mm, F1.4 Zoom: 35x optical, 12x digital Zoom Speed: 3.2/4.6/6.6 seconds Horizontal Angle of View: 55.8° at 3.4mm wide / 1.7° at 119mm tele Focus: Automatic with manual override |
| Iris Operation | Auto with manual override |
| Minimum Illumination |
Color: 0.55 lux at 1/60 sec Color: 0.063 lux at 1/4 sec B/W: 0.00018 lux at 1/2 sec |
| Signal-to-Noise Ratio | >50dB |
| Pan Angle | 360° |
| Pan Speed |
Manual: 0.1-80°/sec Manual Turbo: 150°/sec Preset: 400°/sec |
| Tilt Angle | +2 ~ -92° |
| Tilt Speed |
Manual: 01-40°/sec Preset: 200°/sec (20° without controller) |
| Preset Positions | 256 |
| Controls |
Day/Night Wide Dynamic Range (128x) Electronic Image Stabilization Image Enhancement Electronic Shutter 1/2-1/30,000 (manual/auto) White Balance (automatic with manual override) Gain (auto/off) |
| Video Output | BNC and UTP |
| Audio Output | No |
| Motion Detection | No |
| Sync System | Internal/AC line lock, phase adjustable using remote control, V-Sync |
| Communication Port | Coaxitron, RS-422, RJ-45 (for software update and setup) |
| Communication Protocol | Coaxitron or RS-422 P and D (accepts competitive control protocol with optional translator card) |
| Alarm I/O | 7 Alarm inputs, 2 relay outputs |
| Construction |
Back Box: aluminum Camera: aluminum, thermoplastic Bubble: acrylic Cable Entry: through 1.5-inch NPT pendant mount |
| Power Requirements | 24VAC or 24VDC |
| Power Consumption |
AC: 23VA (73VA with heater) DC: 0.7A (3A with heater) |
| Operating Temperature | 25 - 113°F (-4 ~ +45°C) |
| Diameter and Height | 8.6 x 10.6" (21.8 x 26.9cm) |
| Weight |
Dome Drive: 3.3 lbs (1.5kg) Back Box: 2.4 lbs (1.1kg) Lower Dome: 0.6 lbs (0.27kg) |
