DHI-MCVR6208-G
:
from
to
USA/HDCVI/DVR/Mobile/DHI MCVR6208 G
DHI-MCVR6208-G
| Specifications | Quick Start Guide | Manual | Firmware |
|---|---|---|---|
| Coming Soon |
Series: | Mobile |
| Compatible Video: | HDCVI/CVBS |
| HD-CVI/Analog Channels: | 8 |
| IP Channels: | 0 |
| Video Compression: | H.264 |
| HD-CVI/Analog Recording Resolutions: | Eight (8) Channels at 1080p Real-time Recording |
| IP Recording Resolutions: | - |
| Input Bandwidth: | - |
| Video Output: | One (1) VGA Output Port Two (2) TV Output Ports (includes one aviation connector) |
| HDD: | Two (2) SATA Ports One (1) SD Card Slot, up to 128 GB |
| eSATA: | 0 |
| Audio In: | 2 Channels |
| Audio Out: | 2 Channels |
| Alarm In: | 7 (Two Channels Impulse Input) |
| Alarm Out: | One (1) Digital Output, One (1) Control 12V Output |
| Network: | 1 Gigabit Port |
| USB: | 2 USB 3.0 Ports, 1 USB 2.0 Port |
| Power: | 6 VDC to 36 VDC <12W (No HDD) |
| IVS: | No |
| POS: | No |
| Spot Out/ Video Matrix: | No |
DHI-MCVR6208-GdFeatures
- Supports HDCVI/Analog Video Input
- Dual-stream Recording
- H.264 Video Compression
- Eight-channel 1080p Real-time Recording
- Simultaneous VGA and TV Video Output Channels
- Supports Two (2) SATA HDDs and Three (3) USB Ports
- Aviation Connectors for Increased Signal Stability
- Multiple Network Monitoring Applications: Web Views, CMS, DSS
- 5-year Warranty (for products sold through an authorized iMaxCamPro dealer)
