USA/HDCVI/DVR/Mobile/DHI MCVR5104
DHI-MCVR5104
| Specifications | Quick Start Guide | Manual | Firmware |
|---|---|---|---|
| Coming Soon |
| Series: | Mobile |
| Compatible Video: | HDCVI/CVBS |
| HD-CVI/Analog Channels: | 4 |
| IP Channels: | 0 |
| Video Compression: | H.264, MJPEG |
| HD-CVI/Analog Recording Resolutions: | Two (2) Channels : 1080p at 30 fps, plus Two (2) Channels: 720p at 30 fps |
| IP Recording Resolutions: | - |
| Input Bandwidth: | - |
| Video Output: | One (1) VGA and Two (2) TV |
| HDD: | One (1) SATA Port One (1) Micro SD Card |
| eSATA: | 0 |
| Audio In: | 4 |
| Audio Out: | 1 |
| Alarm In: | 7 |
| Alarm Out: | 2 |
| Network: | 1 Port (10/100 Mbps) |
| USB: | 2 USB 2.0 Ports |
| Power: | 6 V to 36 V <15W (No HDD) |
| IVS: | No |
| POS: | No |
| Spot Out/ Video Matrix: | No |
DHI-MCVR5104Features
- Supports HDCVI/Analog Video Input
- Dual-stream Recording
- H.264 Video Compression
- Two-channel 1080p and Two-channel 720p Real-time Recording
- Simultaneous VGA and TV Video Output Channels
- Aviation Connectors for Increased Signal Stability
- Optional WiFi and GPS Modules Available
- Multiple Network Monitoring Applications: Web Views, CMS, DSS
- 5-year Warranty (for products sold through an authorized iMaxCamPro dealer)
