DH-SD42A212TN-HNI

from

USA/IPCamera/PTZ/Pro/DH SD42A212TN HNI

DH-SD42A212TN-HNI

DH-SD42A212TN-HNI

Specifications

Manual

Firmware

PTZ Firmware

Build Date: 1-16-2018

Build Date: 1-9-2018


Series:	Lite
Body:	PTZ
Image Sensor:	1/2.7 in. CMOS
Resolution:	2 MP, 1920(H) x 1080(V)
Angle of View:	Horizontal: 59.3° to 5.2°
Lens Type:	Varifocal
Focal Length:	5.1 mm to 61.2 mm
Optical Zoom:	12x
Min. Illumination:	Color: 0.05 Lux at F1.6; B/W: 0.005 Lux at F1.6
Day/Night:	Auto (ICR), Color, B/W
Max. IR Range:	-
WDR:	120dB
Video Compression:	Smart H.264+, H.264, MJPEG
Audio Compression:	G.711a, G.711mu, PCM
Frame Rate:	1080p/D1 at 30 fps, 720p at 60 fps
Multi-Streaming:	3 Streams
Pan/Tilt Range:	Pan: 0° to 360° endless Tilt: -2° to 90°, Auto Flip 180°
Preset Speed:	300 Presets Pan: 300° /s Tilt: 200° /s
IVS:	Motion, Tripwire, Intrusion, Abandoned/Missing Object, Facial Detection
ONVIF:	Yes
Audio In:	One (1) Channel
Audio Out:	One (1) Channel
Memory Slot:	-
Alarm In:	Two (2) Channel
Alarm Out:	One (1) Channel
IP Rating:	66
IK Rating:	10
Operating Temp:	–30° C to +60° C (–22° F to +140° F), Less than 90% RH
Power:	24 VAC, 1.5 A (± 10%), PoE+ (802.3at) < 12 W
ePoE:	No
