DH-IPC-EB54A0N
:
from
to
USA/IPCamera/Pro/DH IPC EB54A0N
DH-IPC-EB54A0N
| Specifications | Quick Start Guide | Manual | Firmware |
|---|---|---|---|
Build Date: 9-7-2015 |
EOL Date
- December 31, 2017
Suggested Replacement
- N55BS5 (unreleased coming Nov 2017)
| Series: | Pro |
| Image Sensor: | 1/3" 4MP CMOS |
| Resolution: | 2592×1520 |
| H Field of View: | 185° |
| Min. Illumination: | 0.01 Lux/F2.2 (Color), 0 Lux/F2.2(IR on) |
| Day/Night: | ICR |
| Max. IR Range: | - |
| WDR: | DWDR |
| Compression: | H.264H/MJPEG/JPEG |
| FPS: | 15fps@4MP, 30fps@UXGA |
| Multi-Streaming: | 3 Streams |
| IVS: | - |
| ONVIF: | 2.4 |
| Audio In: | 1 |
| Audio Out: | 1 |
| Built In Microphone: | 1 |
| Memory Slot: | Micro SD-Max 64GB |
| Alarm In: | 1 |
| Alarm Out: | 1 |
| IP Rating: | 67 |
| IK Rating: | 10 |
| Working Temp: | -30°C~+60°C, Less than 95%RH |
| Power: | DC12V, PoE (802.3af) |
| Firmware: | URL |
Features
- 1/3”4Megapixel progressive scan CMOS
- H.264 & MJPEG dual-stream encoding
- Max 15fps@4M(2592×1520), 25/30fps@1080P
- Day/Night(Electronic), 3DNR, AWB,AGC,BLC
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
- 1.18mm fixed lens
- Built-in Microphone
- Micro SD memory, IK10, PoE
CAD Images
Compression
Interfaces
| WebUI Old | SmartPSS | DSS Express S |
|---|---|---|
 |  |  |
Example Photos
Compatible Accessories
| Accessories Combo 1 |  PFA131 | |
| Accessories Combo 2 |  PFB200W | |
| Accessories Combo 3 |  PFA136 | |
| Accessories Combo 4 | PFB200W |  PFA152 |
