Resideo LTEM-PA Advanced Modular Communicator, AT&T, (Replaces VISTAGSMCN4G)
SKU: LTEM-P
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
Product Overview
LTEM-P Communicators utilize the latest LTE® technology specifically designed for loT devices to communicate with AlarmNet®. The CAT-M1 LTE technology, used by leading carriers, has greater signal strength and power efficiency, improving performance underground and within structures. LTE CAT-M1 technology is available everywhere that current LTE networks reach with strong enough reception for consistent connections. The LTEM-P Communicators easily connect to customers' security system control panels and sends alarms and messages to AlarmNet for transfer to the central monitoring station. The LTEM-P Line includes the following models: LTEM-PV (Verizon® network) & LTEM-PA (AT&T® network)The LTEM-P Line also supports these optional plug-in modules:LTE CAT-1 Cell Radio Module for enhanced cellular radio features (model PROLTE series)Wi-Fi®/Z-Wave® Module for Wi-Fi connection to the Internet and/or for control of home automation devices (model PROWIFIZW)Dialer Capture Module for use with control panels that send Contact ID signals via Dialer (model PRODCM)Wi-Fi Module for Wi-Fi connection to Internet
Main Features
- Quick connection to both Resideo control panels (ex. VISTA controls) and compatible non-Resideo (non-VISTA) control panels
- Supports both ECP and Bus connections to compatible control panels
- Power supplied by a 9V DC Power Adapter (included)
- Supports dynamic or static IP addressing, and installs behind firewalls without compromising network security (provided that the Communication Path includes IP)
- Supports connection to the Internet via Ethernet cable or WiFi – only one method can be used, Ethernet or WiFi, not both
- Reports alarms and status messages via the Internet
- Reports messages via cell as backup to Internet reporting (provided that the Communication Path includes cell)
- Allows uploading and downloading of VISTA control panel data
- Supports Remote Services feature, which allows the end user to access their security system from their computer via a website.
- Multi-function Test switch used to generate test messages
General Information
Name: Resideo LTEM-PA Advanced Modular Communicator, AT&T, (Replaces VISTAGSMCN4G)
Category: Resideo, Intrusion, Intrusion, Alarm Communicators & Equipment, Wireless Intrusion, Alarm Communicators, WEC Pro Rewards
UPC Code: 194160005682
Country of Origin: Mexico. Country of origin is subject to change.
| Specifications | Details |
|---|---|
| Brand Name | Resideo |
| Manufacturer | Resideo |
| Manufacturer Part Number | LTEM-PA |
| Product Line / Series | VISTA |
| Product Model | LTEM-P |
| Product Name | LTEM-PA Advanced Modular Communicator (AT&T) |
| Product Type | Burglar Alarm Communicator |
| Weight | 1.54 lb |
| Color | White |
| Country of Origin | MX (Mexico) |
| Installation Type | Professional Install |
| Replaces (ADI Part Number) | 7845I-GSM, GSMX4GP, IGSMV |
| Replaces (Model Number) | 7845I-GSM, GSMX4GP, IGSMV, LTE-IA, VISTAGSMCN4G |
| Compatibility | Interlogix NX-4, NX-6, NX-8, NX-8E; DSC PC1616, PC1832, PC1864; Total Connect 2.0; VISTA-15P, 20P, 21iP, 128BP/BPE/BPT, 250BP/BPE/BPT |
| Certifications & Standards | ETL Listed, UL1023, UL1610, UL365, ULC-S304 |
| Package Contents | LTEM-PA Advanced Modular Communicator (AT&T), 9VDC Power Adapter |
| Technical Information | Details |
|---|---|
| Cellular Generation | 4G LTE |
| Connectivity Technology | Wireless |
| Communication Technology | Internet, Radio |
| Ethernet | Yes |
| Operating Frequency | 700 MHz, 1700 MHz, 1800 MHz |
| Input Voltage | 9V DC |
| Power Source | 9V DC (2.5 A from 102–132V AC, 60 Hz, 0.6 A Power Adapter included) |
| Application/Usage | Internet & Radio Communications |
| Dimensions (H x W x D / L) | 9.1" x 2.2" x 9.1" |
| Features | - Upload/download VISTA control panel data- Multi-function test switch for AlarmNet, pairing, reboot, and reset- Wi-Fi or Ethernet connectivity (one at a time)- ECP & Bus connection support- Alarm/status reporting via Internet or cell backup- Dynamic/static IP addressing- Remote access via AlarmNet 360- Quick install with both Resideo and compatible non-Resideo panels |
