EHV16-480-2T Toshiba 16-Channel Embedded Hybrid Video Recorder, 2 TB
Toshiba was founded in 1938 as Tokyo Shibaura Electric K.K. through the merger of Shibaura Seisaku-sho (founded in 1875) and Tokyo Denki (founded in 1890). The company name was officially changed to Toshiba Corporation in 1978 . Toshiba is organised into four business groupings: the Digital Products Group, the Electronic Devices Group, the Home Appliances Group and the Social Infrastructure Group. In 2010, Toshiba was the world's fifth-largest personal computer vendor measured by revenues (after Hewlett-Packard, Dell, Acer and Lenovo). The EHV16-480-2T Toshiba 16-Channel Embedded Hybrid Video Recorder, 2 TB enable analog and IP video recording for maximum flexibility in a cost effective solution. With up to 16 analog channels, 4 IP channels, and 480 FPS at full D1 resolution, the EHV series provides efficient and reliable video recording. Compatible with Surveillix SCS video management software and MySurveillix for remote access and multi-site deployments for a complete surveillance solution.
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
EHV16-480-2T Toshiba 16-Channel Embedded Hybrid Video Recorder, 2 TB
The Surveillix EHV series hybrid recorders enable analog and IP video recording for maximum flexibility in a cost effective solution. With up to 16 analog channels, 4 IP channels, and 480 FPS at full D1 resolution, the EHV series provides efficient and reliable video recording. Compatible with Surveillix SCS video management software and MySurveillix for remote access and multi-site deployments for a complete surveillance solution.
Features :
Specifications :
The Surveillix EHV series hybrid recorders enable analog and IP video recording for maximum flexibility in a cost effective solution. With up to 16 analog channels, 4 IP channels, and 480 FPS at full D1 resolution, the EHV series provides efficient and reliable video recording. Compatible with Surveillix SCS video management software and MySurveillix for remote access and multi-site deployments for a complete surveillance solution.
Features :
- Up to 16 cameras and 120 FPS at full D1 resolution
- eSATA output for extended storage capabilities
- Local viewing via HDMI, VGA or BNC outputs (HDMI on EHV16-480D model only)
- iPhone/iPad/Android/Blackberry mobile app support
- Maximum of 4 IP camera licenses included
- H.264 compression for maximum video storage
- Remote viewing of IP and analog cameras via browser or VMS software
- 2 TB Storage Capacity
Specifications :
- Max Number of Channels : 16
- Analog Video Channels : 16
- Max IP Video Channels : 4
- Local Display*1 : 1 VGA, 1 BNC, 1 BNC (Call monitor)
- Analog frame rate (analog only) : 480fps@CIF
- Analog frame rate (with IP cameras) : 360fps@CIF
- Analog Compression Format : H.264
- IP Recording Throughput : 32Mbps
- IP Compressions supported : H.264
- Storage Capacity : 2 TB
- Number of HDDs : 2 Internal SATA II
- External Storage : eSATA x 1 (3TB max, 10MB/s speed) *2
- Export formats : AVI, MPEG
- Analog Recording Rate:
- 720 x 480 (analog only) : 120 fps
- Analog Recording Rate:
- 720 x 480 (with IP) : 90 fps
- Analog Recording Rate:
- 720 x 240 (analog only) : 240 fps
- Analog Recording Rate:
- 720 x 240 (with IP) : 180 fps
- Analog Recording Rate:
- 352 x 240 (analog only) : 480 fps
- Analog Recording Rate:
- 352 x 240 (with IP) : 360 fps
- Analog Viewing Rate : 480 fps
- Audio Inputs : up to 4 (4 analog)
- Audio Outputs : 1 RCA Line Out
- USB : 2 USB 2.0
- Alarm IN/OUT : 16/4
- RS-232 : 9 Pin D-Sub Male
- RS-485 : Terminal Block
- Ethernet : 1 Gigabit Ethernet
- Browser Client : Internet Explorer
- Smartphone apps : iPhone/Android/Blackberry
- Tablet apps : iPad/Android
- VMS Software : Surveillix SCS
- Operating System : Embedded Linux
- ONVIF : Version 1.02
- Approvals : FCC Class B, EN55022, EN61000, EN50130, ANSI C63, IEC 0950
- Live screen (client software) : 16 (analog ch, local display), 16 (client software)
- Playback screen (client software) : 16 (client software)
- User Interface control : Mouse and Wireless IR Remote
- Dimension (H x W x D) : 3.46 x 16.53" x 16.85"
- Weight : TBD
- Temperature : Operating: 41° to 104°F
- Humidity : 10% ~ 80% R.H
- Power Input : 12V DC, 5A
- Power Consumption : 60W
