16 CH (HDTVI/HDCVI/AHD/CVBS) CloudVision360 4MP DVR + Cloud Storag

CloudVision360
SKU: WECESAR324-16

CloudVision360 Hybrid DVRs & NVRs are built to work with WEC Cloud Storage technology (powered by Dropbox).

  • CAN BE ACCESSED FROM ANYWHERE
  • DOESN’T GET DAMAGED
  • CAN’T GET STOLENerwer
  • EASY TO UPGRADEgerfg
  • 16Ch Turbo HD DVR, H.265+, HDMI/VGA, 2 SATA, Audio 1-in/1-out, 2 USB2.0, 12V DC, RS-485
  • $399.99
Qty:
OR

Cloud Storage:

  • CAN BE ACCESSED FROM ANYWHERE
  • DOESN’T GET DAMAGED
  • CAN’T GET STOLEN
  • EASY TO UPGRADE
  • CAN ONLY RECORD SUB-STREAM ON THE CLOUD
  • NEED TO SUBSCRIBE TO ONE OF OUR CLOUD STORAGE PLANS (DEPENDING ON HOW MUCH STORAGE YOU NEED)
  • CAN SAVE SNAPSHOTS ON THE CLOUD
  • CAN SAVE VIDEOS (ON MOTION) ON THE CLOUD

Recorder

Video Input and Transmission

  • Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
  • Up to 1-ch 4 MP IP cameras input
  • Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal

Compression and Recording

  • H.265+/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
  • Connectable to H.265+/H.265/H.264+/H.264 IP cameras
  • H.265+ can be enabled to improve encoding efficiency and reduce data storage costs
  • Up to 3 MP resolution for recording Note: The 3 MP signal input is only available for channel 1/2/3/4

Video Output

  • Simultaneous HDMI/VGA output
  • HDMI output at up to 4K (3840 × 2160) resolution
  • Separate CVBS output

Storage and Playback

  • 2 SATA interface (up to 6 TB capacity per HDD)
  • 16-ch synchronous playback
  • Smart search for efficient playback
  • Supports third-party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)

Smart Function

  • Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
  • Supports line crossing detection and intrusion detection of all channels, and 2-ch sudden scene change detection
  • VQD (Video Quality Diagnostics)
  • Supports PTZ control via Omnicast VMS of Genetec protocol

Network & Ethernet Access

  • Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
  • One RJ45 10M/100M/1000M Ethernet network interface
  • Output bandwidth limit configurable
System CompressionH.265+/H.265/H.264+/H.264
Video Interface16-ch, BNC interface
Video ResolutionVGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Recording EncodeWhen 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode enabled: 3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
HDTVI Camera Input3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 Note: The 3 MP signal input is only available for channel 1/2/3/4
HDCVI Camera Input1080p25, 1080p30, 720p25, 720p30
AHD Camera Input1080p25, 1080p30, 720p25, 720p30
CVBS Camera InputPAL/NTSC
IP Camera Input8-ch Up to 4 MP resolution
Bit Rate32 Kbps to 6 Mbps
Audio In1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Out1-ch, RCA (Linear, 1 KΩ)
2 Way AudioSupported
Recording Resolution3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
Recording Frame Rate

Main stream:
When 1080p Lite mode not enabled:
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled: 3 MP@15fps, 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)

Record StreamDual stream recording
Playback Channels16-ch
Alarm InN/A
Alarm OutN/A
Network Interface1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Incoming BandwidthN/A
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
RS4851 x RS-485
USBFront panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0
RS232N/A
RS422N/A
Power Supply12 VDC
Power Consumption≤ 25 W
Internal HDD2 SATA interface, Up to 6 TB capacity for each disk
e-SATAN/A
Operating Conditions-10 °C to +55 °C (+14 °F to +131 °F)
Storage Conditions-10 °C to +55 °C (+14 °F to +131 °F)
Dimensions380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
WeightWeight (without HDD) ≤ 2 kg (4.4 lb)
    • SKU
      WECESAR324-16
  • Manufacturer
    CloudVision360
  • Physical Hard Drive
    1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD, 8TB HDD, 10TB HDD
  • Cloud Storage
    Not Included, 1-Year 3TB Cloud Storage, 1-Year Unlimited Cloud Storage, 2-Year Unlimited Cloud Storage, 3-Year Unlimited Cloud Storage
