Platinum Enterprise Level 32 Channel NVR 2U
More products by
LT Security

Platinum Enterprise Level 32 Channel NVR 2U


(0 reviews)

$2,875.00

$3,590.00

Availability In Stock

SKU LTN0732-R8

Product # 86601

Hard Drive #1

  • 32 Channel Network Video Recorder
  • Video Input: 32CH IP@384Mbps
  • Video Output: VGA/HDMI up to 3840x2160
  • Pentaplex Operation: Record, Playback, Backup, Live & Remote Access
  • Recording Resolution: Up to 8MP (3840x2160)
  • Recording Mode: Manual, Schedule, Video Detection, Motion Detection, Video Loss, Stop
  • Playback Channel: 16CH
  • Playback Resolution: Up to 8MP (4096x2160)
  • Audio In/Out: 1CH/ 1CH, BNC
  • Alarm In/Out: 16/4
  • Network: 10/100/1000M, 2xRJ45
  • Storage: 8 SATA up to 64TB, RAID
                    eSATA, 2 USB 2.0 + 2 USB 3.0, NAS, IP SAN
  • Support POS #: 8
  • Backup: USB, NAS, or eSATA, DVD-RW

Video / Audio input



  • IP video input32-ch
  • Two-way audio input1-ch, BNC (2.0 Vp-p, 1 kΩ)
  • Incoming bandwidth384Mbps
  • Outgoing bandwidth768Mbps
  • Remote connection128


Video / Audio output



  • Recording resolution8MP/5MP/3MP/1080P/UXGA/720P/VGA / 4CIF/DCIF/2CIF/CIF/QCIF
  • HDMI output
  • 2-ch, resolution:
  • HDMI1: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 128 ×0 1024 /60Hz,
  • 1280 × 720 /60Hz,1024 × 768 /60Hz
  • HDMI2: 3840 × 2160P /60Hz, 1920 × 1080P /60Hz,1600 × 1200 /60Hz,
  • 1×28 10024 /60Hz,1 280 × 720 /60Hz, 1024 × 768 /60Hz
  • VGA output
  • 1-ch, resolution:
  • 920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1028 × 720 /60Hz,
  • 1024 × 768 /60Hz
  • Audio output1-ch, BNC (Linear, 600 Ω)
  • Playback resolution8MP/5MP/3MP/1080P/ UXGA/ 720P/ VGA / 4CIF/DCIF/2CIF/CIF/QCIF
  • Synchronous playback16-ch


Hard disk



  • SATAUp to 8 SATA interfaces for 4HDD+1 DVD-R/W, or 8HDDs
  • eSATA1 eSATA interface


Disk array



  • Array typeRAID0, RAID1, RAID5, RAID10
  • Number of array8


External interface



  • Network interface2, 10M / 100M / 1000M self-adaptive Ethernet interface
  • Serial interfaceRS-232, RS-485, RS-485 keyboard
  • USB port2 x USB2.0 + 2 x USB3.0
  • Alarm in/out16/4


General



  • Power supply100 ~ 240 VAC, 6.3A, 50 ~ 60Hz
  • Power Consumption≤100W
  • Working temperature-10°C ~ +55°C (14 °F ~ 131 °F)
  • Working humidity10% ~ 90%
  • Dimension 445 × 470 × 90 mm (17.52" ×18.5"× 3.54")
  • Weight≤ 8 kg (17.64 lb) ( without hard disk or DVD-R/W )
There have been no reviews


 Spec Sheet Spec Sheet (1356 KB)
 Quick Start Guide Quick Start Guide (2578 KB)
User Manual User Manual (9214 KB)
