GV-DFR1352 Door Frame Card Reader
More products by

GV-DFR1352 Door Frame Card Reader

(0 reviews)

Availability In Stock
Ships within 1 to 12 Hours


Product # 82265

GeoVision Authorized Distributor Warranty

The GV-DFR1352 is a card reader designed to be installed on the door frame for recognizing identification cards. Featured with the Wiegand and RS-485 outputs, the unit can be connected to any standard access control panel. GV-DFR1352 comes with a weather sealed and IP66 compliant housing for outdoor use.

Model No. GV-DFR1352 card reader

Ordering Part No. 520-DFR1352-000

SKU 84-DFR1352-1000

CPU 8 bit microprocessor
Frequency 13.56 MHz for ISO14443A (MIFARE DESFire, MIFARE Plus and MIFARE Classic)
Wiegand Interface Wiegand 26 / 34 bit, distance 30 m / 98.43 ft
RS-485 9,600 bps, connect up to 8 GV-DFR1352 units
Power DC 7.5V – 12V
LED Red, Green and Blue LED
Beeper Buzzer
Color Black
Operating Temperature -20 °C ~ 60 °C / -4 °F ~ 140 °F
Operating Humidity 10 ~ 90% RH (non-condensing)
Dimensions (W x H x D) 20.9 x 105.6 x 20.5mm / 0.8 x 4.2 x 0.8 in
Weight 80 g / 0.17 lb
Certification IP66, CE, FCC, RoHS
The number of GV-DFR1352 supported by GV-AS Controllers
GV-AS Controller Model GV-DFR1352 Interface
Wiegand RS-485
GV-AS100 1 1
GV-AS110 / GV-AS120 1 Not support
GV-AS100 / GV-AS110 / GV-AS120 with GV-ASBOX 2 4
GV-AS100 / GV-AS110 / GV-AS120 with GV-ASNet Not Support 2
GV-AS210 4 8
GV-AS400 8 8
GV-AS810 8 8
GV-AS ID Card & GV-AS ID Tag GV-AS ID Cards and GV-AS ID Tags are ideal for business and residential environment, where access control is important for security reasons. 125 kHz and 13.56 MHz cards and tags are available.

GV-DFR1352 Specifications Sheet
