Geovision GV-VD2500 2MP H.264 Super Low Lux WDR IR Vandal Proof IP Dome
More products by
Geovision

Geovision GV-VD2500 2MP H.264 Super Low Lux WDR IR Vandal Proof IP Dome


(0 reviews)

Availability In Stock
Ships within 1 to 12 Hours

SKU GV-VD2500

Product # 86158

Camera Resolution 1920 x 1080

The GV-VD2500 is an outdoor camera (IP67) designed with vandal protection (IK10+). The camera is capable of providing a color live view in near darkness using its super low lux CMOS image sensor. The camera also supports various installations, including wall surface, wall corner, pole and ceiling using the GV-Mount accessories (optional).

Specifications

  • Model No.: GV-VD2500
  • Ordering Part No.: 120VD2500-AOO
  • Sku No.: 84-VD25000-001U
  •

  • 1/2.8" progressive scan super low lux CMOS
  • Min. illumination at 0.02 lux
  • Dual streams from H.264 and MJPEG
  • Up to 30 fps at 1920 x 1080
  • Vandal resistance (IK10+)
  • Ingress protection (IP67)
  • Varifocal megapixel lens
  • 3‐axis mechanism (pan / tilt / roll)
  • Day/Night function (with removable IR‐cut filter)
  • External microphone
  • Intelligent IR
  • IR distance up to 30 m (98.4 ft)
  • Two‐way audio
  • One sensor input and alarm output
  • TV‐out support
  • Built‐in micro SD card slot (SD/SDHC) for local storage
  • NAS Recording
  • Recording assigned by GV‐Edge Recording Manager (Windows, Mac version)
  • DC 12V / AC 24V / PoE (IEEE 802.3af)
  • Wide Dynamic Range (WDR)
  • 3D DNR (Digital Noise Reduction)
  • Defog
  • Motion detection
  • Tampering alarm
  • Privacy mask
  • IP address filtering
  • Supports iPhone, iPad, Android & 3GPP
  • 31 languages on Web interface
  • ONVIF (Profile S) conformant
  •

  • * For optimal performance and compatibility, it is highly recommended to use a GV-NAS System



SPECIFICATIONS
Model GV-VD2500
Camera
Image Sensor 1/2.8” progressive scan super low lux CMOS”
Picture Elements 1920 (H) x 1080 (V)
Minimum Illumination
Color 0.02 Lux
B/W 0.02 Lux
IR ON 0 Lux
Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance Automatic, Manual (2800K ~ 8500K)
Gain Control Automatic
S/N Ratio 52 dB
WDR Pro Yes
Dynamic Range N/A
Lens
Megapixel  Yes
Day/Night Yes (with removable IR‐cut filter)
Focal Length 3 ~ 9 mm
Lens Type Varifocal
Maximum Aperture F/1.2
Mount Ø 14 mm
Image Format 1/2.7”
Horizontal FOV 103°~36°
IR LED Quantity 10 IR LEDs
Max. IR Distance 30 m (98.4 ft)
Focus Manual (w / lock)
Zoom Manual (w / lock)
Iris DC drive
Max. TorquE (Focus/ Zoom Screws) 0.049 N.m
IR LED Quantity 10 IR LEDs
Max. IR Distance 30 m (98.4 ft)
Operation
Video Compression H.264, MJPEG
Video Streaming Dual streams from H.264 and MJPEG
Frame Rate 30 fps at 1920 x 1080 * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
Image Setting Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation, Backlight Compensation, D/N Sensitivity, Shutter Speed, WDR, Defog, Super Low Lux, Denoise, Metering
Audio Compression G.711, AAC (optional)
Audio Support Two‐Way Audio
Sensor Input 1 Input (Dry Contact)
Alarm Output 1 Output (200mA 5V DC)
Video Resolution
Main Stream
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1920 x 1080, 1280 x 720, 640 x 360, 448 x 252
5:4 1280 x 1024, 640 x 512, 320 x 256
Sub Stream
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252
5:4 640 x 512, 320 x 256
Network
Interface 10/100 Ethernet
Ethernet Protocol DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA
Mechanical
Temperature Detector Yes
Camera Angle Adjustment
Pan 0° ~ 350°
Tilt 10° ~ 90°
Rotate 0° ~ 340°
Connectors
Power 2‐pin terminal block, PoE
Ethernet Ethernet (10/100 Base‐T), RJ‐45 cable
Audio 1 In microphone phone jack, 3.5 mm (0.14”) 1 Out Stereo phone jack, 3.5 mm (0.14”)
Digital I/O I/O wire
Local Storage Micro SD card slot (SD/SDHC, SD version 2.0 only, Class 10) * SDXC and UHS‐I card types are not supported.
LED Indicator 2 LEDs: Power, Status
TV‐Out N/A
General
Environment Temperature  ‐30°C ~ 50°C (‐22°F ~ 122°F)
Humidity 10% to 90% (no condensation)
Power Source 12V DC / 24V AC / PoE (IEEE 802.3af)
Max. Power Consumption 12 W
Dimensions
Camera Body 165 x 125 mm (6.49’’ x 4.92‘’)
Cable Length m (3.28 ft.)
Cable Diameter 16.7 mm (0.66’’)
Maximum Connector Diameter ø16.7 mm (0.66’’)
Weight 1.7 kg (3.75 lb)
Ingress Protection IP67
Vandal Resistance IK10+
Regulatory CE, FCC, RCM, RoHS compliant
Power over Ethernet
PoE Standard PoE (IEEE 802.3af Power over Ethernet / PD)
PoE Power Supply Type End‐Span
PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts
Web Interface
Installation Management Web‐based configuration
Maintenance Firmware upgrade through Web Browser or Utility
Access from Web Browser Camera Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Digital I/O Control, Audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ
Language Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek /Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian /Spanish / Swedish / Thai / Traditional Chinese / Turkish
Applications
Network Storage GV‐System (GV‐DVR/NVR), GV‐Backup Center, GV‐Recording Server, GV‐VMS
Smart Device Access GV‐Eye for iOS and Android
Live Viewing IE, mobile phone
CMS Server support  GV‐Control Center, GV‐Center V2, GV‐Vital Sign Monitor



Note:

  • 1. Product design and specifications are subject to change without notice
  • 2. The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
