Geovision GV-IO Sensor Controller
More products by
Geovision

Geovision GV-IO Sensor Controller


(0 reviews)

$90.00

Availability In Stock
Ships within 1 to 12 Hours

SKU GV-IO

Product # 16776

GeoVision Authorized Distributor Warranty

The GV-IO is a 8 point digital input and 16 point digital output controller. The dry relay contacts provide an interface to your external devices such as sensors or detectors.

Specification

INPUT

Input

8

Input Signal

0-5 V DC (floating)

High State

5V

Low State

0V

Wiring Label

GND, DI 1~DI 8

OUTPUT

Output

16

Output Circuit

TTL Open Collect

Wiring Label

+5V-1, DO 1-1 ~ DO 8-1

+5V-2, DO1-2 ~ DO 8-2

Communication

RS485, 9600 bps

RS-485+

Connect to GV-NET RS-485+

RS-485-

Connect to GV-NET RS-485-

DC IN

Power Adapter DC 5V, 2A Inner Positive

Environmental
Condition

Operation temperature

0~50 degree C

Humidity

5%~95% (non-condensing)

Dimension

202(W) x 166(H) x 39(D) mm
