AP-2TB Louroe Electronics Audio Monitoring Base Station - Two-Way
More products by
Louroe Electronics

AP-2TB Louroe Electronics Audio Monitoring Base Station - Two-Way


(0 reviews)

$472.00

$562.00

Availability In Stock

SKU WECAP-2TB

Product # 23827

The Model AP-2TB is a two zone audio monitoring base station designed for two-way listen/talkback. As a complete system using Louroe speaker/microphones, either zone can be monitored by manually pressing the button switch for the desired zone. It has input/output to a DVR/VCR for recording and playback. Contains a 4” speaker for monitoring live audio and playback from a DVR/VCR, and a built-in microphone for providing talkback to the remote zone. A 24 Vdc power supply is included. For two-way listen/talkback, all Louroe Speaker/Microphones (Model TLI, TLM, TLMC, TLSP or TLO) are compatible.

Specifications

  • Input Sensitivity(from remote mic) - 0.78Vrms
  • Input sensitivity (talk-back microphone) - -55 dB
  • Monitor power output - 1W @ 8©
  • Talkback power output(max) - 5W into 70V line
  • Audio output impedance - 600©
  • Audio input impedance - 10k©
  • Audio frequency response - 100 Hz to 10kHz
  • Headphone impedance - 8 to 600©
  • Power input - 24 Vdc, 1A
  • Dimensions -8"W x 10"D x 2 3/8”H
  • Weight - 5.5 lbs (2.5 kg)
