Analog Advanced Level 4 Channel DVR - Compact Case
More products by
LT Security

Analog Advanced Level 4 Channel DVR - Compact Case


(0 reviews)

$85.00

$100.00

Availability In Stock

SKU LTD2304SE-C

Product # 86630

Hard Drive #1

  • 4 Channel Digital Video Recorder
  • Video Input: 4CH
  • Video Output: CVBS, VGA/HDMI
  • Pentaplex Operation: Record, Playback, Backup, Live & Remote Acess
  • Realtime Record: 4CH WD1
  • Recording Rate: 4CH WD1@30fps
  • Playback Channel: 4CH
  • Video Bit Rate: 768 Kbps ~ 2560 Kbps, or user defined (Max. 2560 Kbps)
  • Audio In/Out: 4CH/1CH, RCA
  • Alarm In/Out: 4/1
  • Dual Stream: Support; Master Stream, Sub-Stream: CIF
  • USB: 2 USB 2.0
  • Network: 10/100M
  • Storage: 1 SATA up to 4TB
  • PTZ: 1 RS485
  • Backup: USB, Network

System

  • Compression FormatStandard H.264 Hight profile
  • OSEmbedded Linux


Video

  • Input4CH, BNC (1.0Vp-p, 75Ω)
  • Standard Output1*VGA: 1920x1080,1280x1024, 800x600, 1* BNC+1 Spot out
  • Advanced Output1*HDMI : 1080P: 1920×1080/60Hz
  • AudioAudio Input4CH, RCA (2.0 Vp-p, 1 kΩ)

Audio

  • Output1CH RCA (Linear, 1 kΩ)
  • Bidirectional Talk1-ch, RCA (2.0 Vp-p, 1 kΩ) (using 1ch audio input)

Alarm

  • Alarm in/out4CH/1CH
  • ?960H120(NTSC)/100(PAL)fps
  • D1120(NTSC)/100(PAL)fps
  • CIF120(NTSC)/100(PAL)fps
  • Recording ModeSchedule, Manual,? Motion, Sensor

Playback

  • Max Playback Channel4CH
  • Search Modetime, event, file

Backup

  • USB DiskUSB


Remote Application

  • Dual StreamSupport; master stream, sub-stream @ WD1/D1/CIF
  • BrowserIE (windows XP/2000/Vista/7) , Safari(Mac OS), Chrome,Firefox
  • CMSYES
  • Mobile PhoneBroview for iPad/iPad2/iPhone//Android
  • User Access10users online with professional authority management

Storage

  • HDD1 x SATA, up to 3TB


PTZ

  • PTZ1 RS-485 interface, half-duplex
  • PTZ Protocoll Multiple PTZ protocols supported
  • PTZ ControlPan, Tilt, Zoom, Preset, Cruise, Trace

Network

  • Ethernet1, RJ45 10M / 100M Ethernet interface
  • ProtocolTCP/IP,UDP,DHCP,DNS,PPPoE?DDNS?Email

Others

  • Power SupplyDC12V
  • Consumption≤ 10 W (without hard disk or DVD-R/W)
  • Operating Temperature-10 oC ~+55 oc
  • Humidity10% ~ 90% humidity

Accessories

  • Power Adapter1
  • IR Receiver1
  • Mouse1
  • Screw8
  • Connector5
  • SATA Cable1
  • Cable1 network cable, 1 video cable
  • User Manual(CD)QSG*1; 1 CD

Packing

  • Product Net WeightNW:<2kg
  • Product Dimension300mm ×270mm ×58mm
  • Quantity Box of One Carton5
  • Carton Dimension525mm*415mm*300mm
  • Carton Gross Weight16kg
There have been no reviews


 Spec Sheet Spec Sheet (402 KB)
User Manual User Manual (3287 KB)
